TEC Helical Bevel Gear Motor Part Number WKAZ106 32.68 45.043 225 With an Input Power of 45.0 kW and an Output Speed of: 45 rpm
£7,019.17
Description
Maufacturers Part Number : WKAZ106-32.68-45.043-225. TEC WK Series, Helical Bevel Gearboxes provide a wide range of output speeds and torque requirements for your gearbox requirements. Lightweight, a WK unit is the dependable drive for all applications and
offers the perfect combination in this superb TEC unit. Output Speed (RPM) : 45. Output Torque (Nm2) : 7200. Ratio : 32.68:1. Service Factor : 0.8. Motor Input Frame :225. Input Speed (RPM) : 1440 (4 Pole). If you require additional information
please contact Sales on 01384 402410 or go to the Gearbox Catalogue, WK Series, Page WK36-37
Additional information
Weight | 5665320 kg |
---|---|
Input Power | |
Motor Phase | |
Motor Frame Size | |
Output Speed | |
Output Speed Range | |
Output Torque | |
Ratio | |
Standard Bore Shaft |
